高壓瓷片電容在使用過程中如果使用不當或者是其他的外在因素的影響，都是會出現故障或者是損壞。高壓瓷片電容常見的漏電原因有哪些？

　　High voltage ceramic capacitor in the use process if improper use or other external factors, are likely to failure or damage. What are the common leakage causes of high voltage ceramic capacitor?

　　高壓瓷片電容在正常情況下應是高絕緣的，絕緣值高達1．0E＋9歐姆，多種因素會導致瓷片電容的絕緣下降造成漏電現象。總結有以下兩點原因：

　　Under normal conditions, high voltage ceramic capacitor should be highly insulated with insulation value as high as 1.0e + 9ohm. Many factors may cause the insulation of ceramic capacitor to drop and cause leakage. There are two reasons for this

　　首先是表面臟污引起的表面絕緣下降，這類漏電電流不十分大，一般是微安級別，熱風吹一吹絕緣值會上升。

　　First of all, the surface insulation is reduced due to the surface dirt. This leakage current is not very large, which is generally micro ampere level. The insulation value will rise when the hot air blows.

　　其次內部裂紋，有焊接引起的裂紋和瓷片電容制造不良自帶裂紋。這類裂紋引起的漏電電流會不斷升高，嚴重時會引起局部爆炸起火。

　　Secondly, there are internal cracks, cracks caused by welding and cracks brought by poor manufacturing of ceramic capacitor. The leakage current caused by this kind of crack will increase continuously, and will cause local explosion and fire in serious cases.

　　電容一旦動過烙鐵或升溫，都會恢復正常，許多工程師都往往錯誤的分析為焊錫膏問題，很多人第一次遇到也沒有分析正確，第二次才準確分析，把樣品剖開顯微鏡觀察，確實是電容有問題了。

　　Once the capacitor is moved by the soldering iron or heated, it will return to normal. Many engineers often mistakenly analyze the problem as solder paste. Many people do not analyze it correctly for the first time, and then analyze it accurately after the second time. When the sample is dissected and observed by microscope, it is indeed that there is something wrong with the capacitor.

　　對于高壓瓷片電容漏電從可靠性角度說，是屬于典型的低應力失效，多層陶瓷電容、繼電器、滌綸電容都有這些問題。如果供電不干凈導致，比如直流電壓異常，即使電容的額定電壓是50V、25V的也會漏電，但是在1~10V之間的這種電容最為嚴重，它在這種直流電壓異常的情況下工作一定時間后，就會漏電，而且隨時間增長越來越多，越來越嚴重。

　　From the reliability point of view, the leakage of high-voltage ceramic capacitor is a typical low stress failure. Multilayer ceramic capacitor, relay and polyester capacitor all have these problems. If the power supply is not clean, such as abnormal DC voltage, even if the rated voltage of the capacitor is 50V or 25V, it will leak, but the capacitor between 1 ~ 10V is the most serious. After working for a certain period of time under the condition of abnormal DC voltage, the leakage will be more and more serious with time.

　　如果想要避免這樣的情況出現，就要選擇正規廠家的知名品牌的電容。山東紅寶電子有限公司主要經營各種類型的電容元器件，包括：電解電容、高壓瓷片電容、薄膜電容、超級電容、貼片電容等等，是韓國三和電容的特約代理商。

　　If you want to avoid such a situation, you should choose the capacitor of well-known brand of regular manufacturer. Shandong Hongbao Electronic Co., Ltd. mainly deals in various types of capacitor components, including electrolytic capacitor, high voltage ceramic capacitor, thin film capacitor, super capacitor, chip capacitor and so on.
