薄膜電容器有多種不同種類及型號，根據使用場景的區別選擇適合型號的電容。今天我們主要來了解下有機薄膜電容器。有機薄膜電容有哪些優點內容？

　　There are many different types and models of thin-film capacitors. The suitable type of capacitors can be selected according to the different use scenarios. Today we are going to talk about organic film capacitors. What are the advantages of organic film capacitors?

　　1.體積縮小可取代以往使用電解電容的場合，并且具有更高的耐電壓能力；

　　The volume reduction can replace the previous occasions where electrolytic capacitors are used, and has higher voltage resistance;

　　2.不存在電解液泄露風險，具有更高的可靠性；

　　There is no risk of electrolyte leakage, so it has higher reliability;

　　3.在電路中遇到瞬時過壓時，具有自愈特性，能夠很好地保護電路安全，消除電路過壓擊穿短路風險；

　　When the circuit encounters instantaneous overvoltage, it has self-healing characteristics, which can well protect the circuit safety and eliminate the risk of circuit over-voltage breakdown and short-circuit;

　　4.采用無感卷繞技術，產品符合低電感特性，更能適應電源系統不斷提升的工作頻率；

　　Adopting non inductive winding technology, the product meets the low inductance characteristics, and is more suitable for the rising working frequency of the power supply system;

　　5.采用低損耗介質材料，產品具有低損耗特性，能夠承受更大紋波電流，發熱量較低；

　　Using low loss dielectric material, the product has low loss characteristics, can withstand larger ripple current, and has lower heating capacity;

　　6.無極性介質材料，能夠承受反峰電壓，可滿足交、直流濾波電路使用等。

　　Nonpolar dielectric material, able to withstand reverse peak voltage, can meet the use of AC and DC filter circuit.

　　金屬化有機薄膜電容器的自愈有兩種不同的機理：一種是放電自愈；另一種是電化學自愈。前者發生在電壓較高下，所以也簡稱為高壓自愈；因為后者在電壓很低的情況下也出現，所以常簡稱為低壓自愈。

　　The self-healing mechanism of metallized organic film capacitor has two different mechanisms: one is discharge self-healing; the other is electrochemical self-healing. The former occurs at a higher voltage, so it is also referred to as high voltage self-healing; because the latter also occurs in the case of very low voltage, it is often referred to as low-voltage self-healing.

　　金屬化有機薄膜電容器的最大特點是具有自愈能力，因此自愈所帶來的好處是主要的，但是，它也有不利之處，其中最大的害處就是自愈時造成電流脈沖，給電路帶來信號干擾，降低電路的重要性能——信噪比。所以對于一些要求特別高的電路，如高保真音響電路、高精度通信電路等，不能讓有機薄膜電容器在工作時發生自愈。

　　The biggest characteristic of metallized organic thin film capacitor is its self-healing ability, so the advantages brought by self-healing are main. However, it also has disadvantages. The biggest harm is the current pulse caused by self-healing, which brings signal interference to the circuit and reduces the important performance of the circuit signal-to-noise ratio. Therefore, for some circuits with high requirements, such as high fidelity audio circuit, high-precision communication circuit, the organic film capacitor can not be self-healing when working.

　　自愈的另一害處，是使用電容器的容量逐漸減少。若電容量在工作時，自愈次數很多，就會導致其容量和絕緣電阻顯著變小、損耗角大幅度上升，使電容器很快失效。

　　Another disadvantage of self-healing is that the capacity of capacitors is gradually reduced. If there are many self-healing times when the electric capacity is working, its capacity and insulation resistance will be significantly reduced, and the loss angle will be greatly increased, which will make the capacitor fail quickly.

　　總而言之，有機薄膜電容的應用還是利大于弊，企業在購買有機薄膜電容器的時候要根據電容器的使用環境、電路特征等綜合因素選擇適合的電容元器件。更多相關電容元器件型號及種類請移步至產品中心：http://www.dsbb.net.cn/cn/product/。

　　In a word, the advantages and disadvantages of the application of organic thin film capacitors are greater than the disadvantages. When purchasing organic thin film capacitors, enterprises should choose the appropriate capacitor components according to the comprehensive factors such as the operating environment and circuit characteristics of the capacitors. For more models and types of capacitor components, please move to the product center.
